Face Recognition And Temperature Measurement Automatic Face Access
Control Machine
Product Features
1. Intelligent face access control and temperature measuring
machine: face temperature measurement, access control and
attendance, infrared detection scanning, AI algorithm recognition,
face mask detection.
2. A number of core technologies: a variety of black technology,
only for your use, infrared scanning, a variety of temperature
measurement mode, remote background, industrial motherboard,
binocular camera.
3. Support multi-functional system docking: it can dock with
various applications developed by partners, such as ticketing,
access control, attendance, visitors, authentication, building
management system, and developers can develop their own
applications according to the product interface.
4. Perfect software interface: convenient for equipment management,
personnel / photo management, record view and other functions.
5. Waterproof and dustproof, suitable for outdoor environment:
waterproof and dustproof, make the product more durable, easy to
adapt to outdoor environment.
6. New experience of face brushing: dynamic face, easy recognition.
2 million high-definition dynamic recognition, infrared multi wide
element three-dimensional imaging technology, zero generation
punch, adapt to various environments.
7. Super function intelligent enjoyment: recognition rate > 99%,
temperature detection, high temperature accuracy, abnormal warning.
8. Face recognition is more accurate due to its anti clock and wide
dynamic camera.
9. Humanized matching function: it can support NFC card swiping /
multi-functional identification / optional customized ID card and
IC card identification module.
10. Industrial motherboard, smooth operation, not stuck: no
temperature measurement when the background shutdown, refused to
crash heating stuck.
Applicable to office areas, hotels, office buildings, schools,
shopping malls, shops, communities, public services and management
projects that need to use face access control places.
Technical parameter:
| Screen | 8 inch |
| Overall size | Long 284* width 140*high29mm |
| processor | High performance 32 bit 4 core ARM chip |
| Storage memory | 16GB |
| Measurement mode | Infrared thermal imaging temperature measurement |
| Measuring distance | 0.3m~1m(suggest 0.5m) |
| communication method | TTL |
| Temperature measurement accuracy | ±0.2℃~±0.4℃ |
| Operating temperature | -20~65℃ for |
| Storage temperature | -40~65℃ for |
| Power supply | 3-5V |
| Electric current | 2ma |
| Baud rate | 9600/115200 |
| Default automatic output frequency | 14Hz |
| Wavelength range | 8~14µm |
| Temperature output | parallel output at any time |
| Temperature correction | Manual and automatic calibration |
| Alarm threshold | Adjustable |
| Wiegen interface | Support weigen 26 weigen34 |
| Other interface | 232 TTL WIFI RJ45 |
| Type | Can be wall-mounted, desktop, vertical, gate |
camera | 200w:USBConnector,Binocular wide dynamic,Glare |
| Aperture 2.8,Focal length 1.6mm,Angle of view 130°,TV
distortion<-5%,Photosensitive area size1/5-inch |
| Pixel:meet customer’s need,≥2 million pixels |
| Assembly angle: flat out |
| Image Sensor | 6mm Focal length,F2.4 Aperture |
| Fill light | LED:white light,RGBCamera fill light,SDK with control interface |
NIR:850nm Infrared LED light,IR Camera fill light source,SDK with control interface |
| Operating system | Android 6.0.1 or above |
| Input power | 12V2A |
| Backlight identification illuminance | <6000Lux |
| Effective identification distance | 0.5m-4m |
| working environment | Indoor,outdoor(With rainproof frame),10~90%(Non-condensing) |
| Operating temperature | -20℃~+55℃ |
| Card reading speed | 0.2S |
| Matching |
| ID card reader | Support second-generation ID card identification function, SDK
contains control interface |
| LTE Function | Support 4G full Netcom Internet access function |
