Industrial Control Host Four Core Core Dual Network Port Six Serial
Port Fanless Totally Enclosed Computer
Industrial fully enclosed industrial control host, aluminum alloy
shell, metal grid heat dissipation, strong configuration, high
performance, rich interface design, USB interface, 232 serial port,
485 serial port, synchronous / asynchronous dual display, WiFi
support. It can be widely used in all aspects of industry and
people's life.
1. High performance industrial control computer, automatic control,
industrial places, digital signs, multimedia education; With
multiple serial port RS232, RS485 interface, easy to adapt to a
variety of devices, support 4G module, 7 * 24-hour all-weather
operation, aluminum alloy shell fin heat dissipation.
2. Basic parameters: high speed processor, n2930, i3-3217u,
i5-3317u, etc; Running memory: 2G / 4G / 8gddr4 optional; SSD: 32g
/ 64g / 128G / 256g / 512g / 1t SSD optional; Bring your own WiFi;
Material: aluminum alloy + galvanized steel plate; Support power
on.
3. Wide range of applications: compared with ordinary computers,
industrial computer has unique advantages, which has been widely
used in all aspects of industrial people's life; Can be used in
public places, leisure and entertainment, industrial places,
commercial institutions, financial institutions and so on. It has
strong configuration, no fan, energy saving and environmental
protection, beautiful and light, and unique heat dissipation
design, so it is more affirmed by customers. It is suitable for use
in many places and meets customers' requirements in special scenes.
| Production specifications |
| Color | silver |
| SIZE | 21cmx 20cm x5 cm(Length, width, height) |
| Structure | all-aluminium Alloy fan-less enclosure for heat dissipation |
| Material Quality | Aluminium Alloy+Galvanized Steel |
| Memory | one DDR3L/1,.35 memory ,up to 8G( Optional) |
| 2.5Hard Disk | Capacity 500G(Optional) |
| CF | N/A |
| SSD | N/A |
| POWER | Standard 12V or 5V adapter(optional) |
| Installation mode | Desktop or wall mounted |
| Operating temperature | -10℃-60℃ |
| Storage temperature | -20℃-90℃ |
| Relative humidity | 5%-95% No condensation |
| Working Vibration | 0.5grms/5-500HZ/random/oper ating |
| Motherboard type | National Solid State Capacitor motherboard |
| Processor | Intel arena j1800/j1900 Core I3/I5/I7 |
| Graphics Cards | Collection inter HD key graphics cards |
| WEB | Collection 1x inter WG Gigabit network cards, Support Network
wake-up /PXE function |
| USB | 8*USB |
| Interface | 6*RS232 Serial port |
| Display | 1*VGA 1*HDMI |
| Audio | 1*MIC,1*Line-out |
| Expansion slot | 2*MINIPCIE(1*WIFI 1*MSATA) |
| Indicator Lights | Power indicator lights |
| System control | The power switch |
| wireless | 2*WIFI/3G SMA antenna (optional) |
