Brand Name : | LIQUISE |
Model Number : | XHT800 |
Certification : | CE/CCC/FCC/ISO9001 |
Price : | Face to face |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability : | 1000 Piece/Pieces per Week |
Delivery Time : | 5-7 days |
Face Recognition, Temperature Measurement And Contactless Face
Brushing System For School In Office Building
Product Features
1. Product parameters: attendance machine type: voice,
multi-functional integration; Attendance authentication method:
face recognition, fast temperature measurement, high temperature
alarm. Factory direct sales, three-year warranty, 180 day
replacement. Industrial motherboard, fine and small, suitable for
small display terminal equipment, smooth operation, no stuck, no
temperature measurement when the background shutdown, refuse to
crash heating stuck. Aluminum alloy material, pure graphic design,
dustproof and waterproof, accurate identification at night.
2. Application scenarios, product diversification applications,
flexible application in a variety of scenarios. Transportation,
government agencies, offices, gyms, enterprise attendance, visitor
registration, etc. Dynamic face, easy recognition, the camera of
the product can quickly capture the face information, can realize
the second speed traffic. A variety of recognition functions, such
as face or swipe card, can be used to open the stranger visit
record. Whether there is information collection or not, all the
pass records will be recorded.
3. With the gate, fast detection, set image acquisition, face
detection, face tracking, face contrast, living judgment in one.
The spray disinfectant is equipped with vertical disinfectant,
loaded with disinfectant, palm facing the nozzle, the machine
automatically detects human hands, and the disinfectant is sprayed
out in the form of spray. Every bright spot is made with sincerity.
The motherboard fits the aluminum alloy back cover with fast heat
dissipation. Turning and milling the back cover has higher
precision than traditional die casting.
Applicable to office areas, hotels, office buildings, schools,
shopping malls, shops, communities, public services and management
projects that need to use face access control places.
Technical parameter:
Screen | 8 inch |
Overall size | Long 284* width 140*high29mm |
processor | High performance 32 bit 4 core ARM chip |
Storage memory | 16GB |
Measurement mode | Infrared thermal imaging temperature measurement |
Measuring distance | 0.3m~1m(suggest 0.5m) |
communication method | TTL |
Temperature measurement accuracy | ±0.2℃~±0.4℃ |
Operating temperature | -20~65℃ for |
Storage temperature | -40~65℃ for |
Power supply | 3-5V |
Electric current | 2ma |
Baud rate | 9600/115200 |
Default automatic output frequency | 14Hz |
Wavelength range | 8~14µm |
Temperature output | parallel output at any time |
Temperature correction | Manual and automatic calibration |
Alarm threshold | Adjustable |
Wiegen interface | Support weigen 26 weigen34 |
Other interface | 232 TTL WIFI RJ45 |
Type | Can be wall-mounted, desktop, vertical, gate |
camera | 200w:USBConnector,Binocular wide dynamic,Glare |
Aperture 2.8,Focal length 1.6mm,Angle of view 130°,TV distortion<-5%,Photosensitive area size1/5-inch | |
Pixel:meet customer’s need,≥2 million pixels | |
Assembly angle: flat out | |
Image Sensor | 6mm Focal length,F2.4 Aperture |
Fill light | LED:white light,RGBCamera fill light,SDK with control interface |
NIR:850nm Infrared LED light,IR Camera fill light source,SDK with control interface | |
Operating system | Android 6.0.1 or above |
Input power | 12V2A |
Backlight identification illuminance | <6000Lux |
Effective identification distance | 0.5m-4m |
working environment | Indoor,outdoor(With rainproof frame),10~90%(Non-condensing) |
Operating temperature | -20℃~+55℃ |
Card reading speed | 0.2S |
Matching | |
ID card reader | Support second-generation ID card identification function, SDK contains control interface |
LTE Function | Support 4G full Netcom Internet access function |
![]() |
