10 / 12 / 15 Inch, Capacitive Touch Screen, Android Industrial
Tablet, Embedded Industrial PC
Industrial control all-in-one machine, including embedded
industrial touch all-in-one machine, wall mounted industrial touch
integrated machine and other styles. Independent research and
development of the whole machine, industrial Android tablet
computer, create a new interactive experience.
1. It is durable, flexible in configuration, integrated machine of
industrial touch control, strong protection and industrial control
LCD.
2. Complete process equipment interface: rich interface can expand
your need for more convenient peripheral, USB, HDMI, VGA, LAN, etc.
3. Details determine the future: Fashion slim design,
wear-resistant anti-corrosion grinding technology.
4. Precise touch is more flexible: touch the precise and sensitive
experience, feel the fingertip screen hand feeling combined with a
smooth and comfortable operation experience.
5. Function effect: support 365 * 24 hours continuous operation,
ultra-low power consumption.
6. LED backlight HD display: high definition picture quality
output, vivid led bright color backlight, dynamic and even
distribution of back light source, more rich painting quality.
7. Industrial special industrial control a gauge screen, same
display and display: can support synchronous display / synchronous
display.
8. Full enclosed military class, all aluminum shell, dust-proof
design: use strong and tough to challenge the harsh working
environment, and the fully closed design is more effective in dust
prevention, oil prevention and water proofing.
9. Intelligent manufacturing, customized: upgrade memory,
appearance customization, interface customization, color
customization.
10. Installation mode: the installation support is provided, and
the installation methods such as wall hanging, rack type, desktop
and embedded can be flexibly fixed on the desktop and wall. Save
space, easy and quick installation.
Brand:LIQUISE Screen specifications: 15 inches Screen ratio: 4:3 Resolution: 1024x 768 Backlight type: LED Motherboard: J1800/J1900 industrial control motherboard | Memory: 2G/4G/8G (upgradeable) Interface: VGA x 1HDMIx 1USBx4L AN
x 1COM x 2 audio input/output x 1DC Power connector x 1 Network card: Built-in Gigabit network card Graphics: Integrated HD
|
Common system: win7/win10/Android Normal power: ≤40W Working temperature: -10C~+60C Environmental humidity: 20%~70% Product certification: CE, FCC, CCC Applicable industries: Industry, Commerce
| Touch screen: Resistive/Capacitive Response time: 5ms Display brightness: 350cd/m2 Contrast ratio: 1000:1 Color depth: 16.7M CPU: Celeron dual-core 2.41GHz/quad-core 1.99GHz
|
Power supply: External power supply 12V Special structure: Fanless dustproof structure Aluminum alloy cooling back cover Can be installed and built-in: Wireless wifi, 4G,
Bluetooth(optional) Viewable size: 304mm x 228mm Shell size: 378mm x 297mm
| Bracket hole: 75mm x 75mm Appearance material: Metal cold rolled sheet Bracket: Wall Hanger / Die-casting desktop bracket (optional) |
Capacitor size Shell width(mm)
Shell heigh(mm)
Thickness(mm)
Screen width(mm)
Screen heigh(mm)
Screen Resolution (mm) Wall hole position (mm) Screen width:height
| 8.4inches 236
190
51.5
170.4
127.8
800*600
100*100
4:3
| 10.4 inches 283
225.2
56.2
213.1
160.3
1024*768
100*100
4:3
| 12.1 inches 317
258
56.2
246
184.5
1024*768
100*100
4:3
| 15 inches 378
297
56.2
304
228
1024*768
100*100
4:3
| 17 inches 413
342
56.2
338.92
271.34
1280*1024
100*100
4:3
| 19 inches 454
375.5
62.7
377.3
302.1
1280*1024
100*100
4:3
| 22 inches 559
349.3
65.5
477.6
261.1
1920*1080
100*100
16:9
|
