HD big tv monitor screen LCD splicing display panels wifi
advertising player
Description of LCD Video Wall
Excellent super narrow bezel design with just 3.5 mm bezel width
between screens
Built-in 3D noise reduction, making the image clean and outline
more vivid
FHD display 1920x1080
LED backlit technology brings you perfect visual effect
4K input supported (Option)
Built-in speakers and remote control supported
Available sizes: 42",46”, 47”, 49, 55”, 60”
Advantages of LCD Video Wall
Reliable quality and low maintenance: Less thermal diffusivity
makes the components and parts more stable.
High Definition and clear image: High brightness and contrast make
colors brilliant and bright, as well as stable and clear image.
Wide viewing angle: DID LCD panel makes the viewing angle up to
180°.
Low power consumption and low heat radiation
Long service life lowers the cost of usage and maintenance
Innovative and advanced: 42” to 60” Ultra thin bezel LCD video
wall, the thinnest bezel up to 1.8mm
Ultathin and lightweighted: The ultra thin and lightweighted design
makes it easy to transport and install.
Economical and practical: High performance and high quality make it
cost less.
| Panel | Brand | S-series | L-series | B-series |
| Panel size | 46 55 65 inch optional | 49 55 inch optional | 46 49 55 inch optional |
| Bezel | 1.7/3.5/5.5mm | 0.88/1.8/3.5mm | 0.99/3.5mm |
| Resolution | 1920×1080 | 1920×1080 | 1920×1080 |
| Brightness | 500~700 cd/m² | 500~700 cd/m² | 500~700 cd/m² |
| Constract ratio | 1200:1, 3500:1, 4000:1 | 1200:1, 1300:1, 1400:1 | 1300:1, 1400:1 |
| Viewing angle | 89/89/89/89 | 89/89/89/89 | 89/89/89/89 |
| Color | 16.7M , 72% (CIE1931) | 16.7M , 72% (CIE1931) | 16.7M , 72% (CIE1931) |
| Backlit | WLED | WLED | WLED |
| Frequency | 60Hz | 60Hz | 60Hz |
| Signal interface | LVDS | LVDS | LVDS |
| Repond time | 8ms | 8ms | 8ms |
| Life spang | 60000 hours | 60000 hours | 60000 hours |
| I/O | Interface | HD Interface, VGA in, DVI, BNC, Support Picture in
Picture(PIP/POP/PAP) |
| Concatenation port | RS232-RJ45 in/out |
| Video | Color system | PAL/NTSC/Auto-Identify |
| Scene roaming | Support |
| Power | Power input | Build-in type, 100 ~ 240V AC, 50/60Hz |
| Power consumption | 180W (Max.); standby power lesss than 3w |
| Outlook | Shell material | Cold-rolled sheet, black |
| Screen position | Landscape, protrait optional |
| Unit demenssion | 1210.81(L)*681.52(W)*63.24+45(thickness)mm |
| Optional | Installation | Floor standing cabinet/bracket, and wall mounted bracket optional |
| Touch screen | IR touch screen optional |
| Splitter & matrix | 1ch in, 4/8/12/16ch out splitter optional; Matrix optional |
| Package | Unite Package | PE film + Foam corner protector + honeycomb box |
| Export Package | Export wooden box or wooden pallet |
| Accessories | HD cable, RJ45 cable, remote control*1, IR sensor*1 |
