19 Inch Embedded Fully Enclosed Touch Screen Industrial All In One
Machine
Industrial control all-in-one machine, including embedded
industrial touch all-in-one machine, wall mounted industrial touch
integrated machine and other styles. Independent research and
development of the whole machine, industrial Android tablet
computer, create a new interactive experience.
1. Subvert the tradition, break through the industry restrictions:
face value and strength of the co-existence of fully enclosed
embedded industrial control all-in-one machine.
2. Brand authority certification: high tech enterprises,
standardized production enterprises.
3. Scene display: Super applicability, can adapt to more harsh
environment, stable use.
4. Die casting private mold, all aluminum body: Die Casting fully
closed fan less heat dissipation, rear cover all aluminum fin
design.
5. Not only to upgrade, but also to win quality: high
configuration, high technology, high enjoyment, give you a new
experience.
6. Full closed integrated back cover, burst performance, strength
attack: all aluminum alloy integrated back cover, strong hardness,
pressure resistance, durable, embedded installation and fitting
terminal equipment.
7. Play high-tech, immersive quiet experience: fully enclosed
fanless dust-proof design, better and more stable heat dissipation
performance.
8. Both the appearance value and the heat dissipation strength: the
running speed is fast, the performance is stable, and the heat
dissipation effect of the whole machine is improved several times.
9. Seamless design, consistent inside and outside: dust proof,
splash proof, oil proof, break through environmental restrictions,
more suitable for industrial automation equipment in harsh
environment.
10. All aluminum alloy fuselage, solid as a rock: metal material,
strong quality, thin between, create the beauty of both internal
and external repair.
Brand:LIQUISE Screen specifications: 15 inches Screen ratio: 4:3 Resolution: 1024x 768 Backlight type: LED Motherboard: J1800/J1900 industrial control motherboard | Memory: 2G/4G/8G (upgradeable) Interface: VGA x 1HDMIx 1USBx4L AN
x 1COM x 2 audio input/output x 1DC Power connector x 1 Network card: Built-in Gigabit network card Graphics: Integrated HD
|
Common system: win7/win10/Android Normal power: ≤40W Working temperature: -10C~+60C Environmental humidity: 20%~70% Product certification: CE, FCC, CCC Applicable industries: Industry, Commerce
| Touch screen: Resistive/Capacitive Response time: 5ms Display brightness: 350cd/m2 Contrast ratio: 1000:1 Color depth: 16.7M CPU: Celeron dual-core 2.41GHz/quad-core 1.99GHz
|
Power supply: External power supply 12V Special structure: Fanless dustproof structure Aluminum alloy cooling back cover Can be installed and built-in: Wireless wifi, 4G,
Bluetooth(optional) Viewable size: 304mm x 228mm Shell size: 378mm x 297mm
| Bracket hole: 75mm x 75mm Appearance material: Metal cold rolled sheet Bracket: Wall Hanger / Die-casting desktop bracket (optional) |
Capacitor size Shell width(mm)
Shell heigh(mm)
Thickness(mm)
Screen width(mm)
Screen heigh(mm)
Screen Resolution (mm) Wall hole position (mm) Screen width:height
| 8.4inches 236
190
51.5
170.4
127.8
800*600
100*100
4:3
| 10.4 inches 283
225.2
56.2
213.1
160.3
1024*768
100*100
4:3
| 12.1 inches 317
258
56.2
246
184.5
1024*768
100*100
4:3
| 15 inches 378
297
56.2
304
228
1024*768
100*100
4:3
| 17 inches 413
342
56.2
338.92
271.34
1280*1024
100*100
4:3
| 19 inches 454
375.5
62.7
377.3
302.1
1280*1024
100*100
4:3
| 22 inches 559
349.3
65.5
477.6
261.1
1920*1080
100*100
16:9
|
